Honeywell TH5220D1029 Installation Guide
This guide details the installation of the Honeywell FocusPRO 5000 Series thermostat, covering wallplate setup, wiring, and configuration for optimal heating and cooling control.
The Honeywell TH5220D1029 is a non-programmable, digital thermostat designed for reliable and straightforward temperature management within your home or office. As part of the FocusPRO 5000 Series, it offers essential heating and cooling control without the complexities of programmable schedules. This thermostat is compatible with a wide range of heating and cooling systems, including conventional and heat pump setups.
This installation guide provides step-by-step instructions for a successful setup, ensuring accurate operation and maximizing energy efficiency. Whether you’re replacing an existing thermostat or installing a new one, this document will walk you through the process, from wallplate installation and wiring to system configuration. Careful adherence to these instructions is crucial for optimal performance and safety.
Package Contents
Upon opening the Honeywell TH5220D1029 package, please verify that all components are present and undamaged. The standard package includes the following items: one (1) Honeywell FocusPRO TH5220D1029 Non-Programmable Digital Thermostat unit, one (1) Wallplate – this serves as the mounting base for the thermostat and facilitates wiring connections. You will also find a bag containing mounting screws and wall anchors, essential for securely attaching the wallplate to the wall.
Additionally, the package contains wire labels to help identify the existing wiring during installation, simplifying the connection process. Finally, this installation guide is included to provide clear, step-by-step instructions. If any components are missing or appear damaged, please contact Honeywell customer support immediately before proceeding with the installation.
Safety Precautions
Prior to commencing the installation of your Honeywell TH5220D1029 thermostat, it is crucial to prioritize safety. Always disconnect power to your heating and cooling system at the breaker box or fuse panel to avoid electrical shock. Exercise caution when working with wiring, and if you are uncomfortable or unfamiliar with electrical work, consult a qualified HVAC technician.
Ensure the thermostat is installed in a location free from direct sunlight, drafts, and excessive moisture, as these can affect its accuracy. Keep the thermostat and packaging out of reach of children. Do not attempt to disassemble or repair the thermostat beyond the instructions provided in this guide; Improper installation can lead to system malfunction or safety hazards. Always adhere to local electrical codes.
Installation Process
Begin by carefully removing the existing thermostat and preparing the wall for the new Honeywell TH5220D1029, followed by wiring and mounting procedures.
Wallplate Installation
Proper wallplate installation is crucial for a secure and functional thermostat setup. Begin by carefully removing the existing thermostat’s wallplate, ensuring all wires are labeled before disconnection to avoid confusion during reconnection. The Honeywell TH5220D1029 wallplate should be mounted level on the wall, utilizing the provided screws and anchors if necessary.
Ensure the wallplate is positioned away from direct sunlight, drafts, or other sources of temperature interference. Double-check that the wires pass through the opening in the wallplate smoothly. A correctly installed wallplate provides a stable base for the thermostat and facilitates easy wiring connections, contributing to the overall reliability of the heating and cooling system.
Removing the Wallplate
Before installing the new Honeywell TH5220D1029 thermostat, carefully remove the existing wallplate. First, power down your HVAC system at the breaker to prevent electrical shock. Gently detach the old thermostat from the wallplate; it usually snaps or unscrews. Crucially, before fully removing it, label each wire connected to the terminals.
Use the provided labels or create your own detailed notes, as accurate wire identification is vital for correct reconnection. Once all wires are labeled, disconnect them from the old wallplate. Finally, unscrew the wallplate from the wall, taking care not to damage the surrounding surface. Proper removal ensures a smooth transition to the new thermostat installation.
Power Options
The Honeywell TH5220D1029 thermostat offers flexible power solutions: battery power or optional 24VAC power. For battery operation, insert two AA alkaline batteries into the battery compartment, ensuring correct polarity. Batteries serve as primary or backup power, maintaining thermostat functionality during power outages.
Alternatively, you can connect to a 24VAC power source for continuous operation. Important: If utilizing 24VAC, ensure a disconnect means and overload protection are in place. A factory-installed jumper must be removed for two-transformer systems when using 24VAC. The C (common) wire is optional when running solely on battery power.
Battery Installation
To install batteries, locate the battery compartment on the back of the thermostat. Gently slide open the battery compartment cover. Insert two fresh AA alkaline batteries, paying close attention to the polarity markings (+ and -) inside the compartment. Incorrect battery installation will prevent the thermostat from operating correctly.
Ensure the batteries are securely seated within the compartment. Once the batteries are properly installed, slide the compartment cover closed until it clicks into place. Batteries provide a reliable power source, especially useful during power outages, maintaining your programmed settings and ensuring continued climate control.
AC Power Connection (Optional)
For optional AC power, locate the M29370 terminal block on the thermostat’s backplate. Connect the 24VAC common (C) wire to this terminal. Ensure the power supply provides the correct voltage and is appropriately fused for overload protection, adhering to local electrical codes. This connection provides continuous power, eliminating the need for frequent battery replacements.
If using AC power, batteries serve as backup during power outages, preserving settings. The thermostat automatically switches to battery power when AC power is interrupted. Remember to disconnect power before making any wiring connections. Proper AC power installation ensures reliable and consistent thermostat operation, enhancing comfort and energy efficiency.
Wiring
Proper wiring is crucial for correct thermostat operation. This section details connections for conventional and heat pump systems, ensuring accurate temperature control and system functionality.
Wiring Conventional Systems
Connecting the thermostat to a conventional heating and cooling system requires careful attention to wire identification. Typically, the Red wire provides power, while the White wire controls the heating function. The Yellow wire activates cooling, and the Green wire manages the fan.
Ensure the power is OFF before commencing any wiring. Connect these wires to the corresponding terminals on the thermostat wallplate. A factory-installed jumper may need removal for two-transformer systems, as detailed in the installer setup section.
Double-check all connections for security and proper placement. Incorrect wiring can lead to system malfunction or damage. Refer to the wiring diagram included with your thermostat for a visual guide and always prioritize safety during installation.
Identifying Conventional System Wires
Accurate wire identification is crucial for a successful installation. The Red wire generally carries 24VAC power from the heating/cooling system’s transformer. White typically controls the heating function, signaling the furnace to ignite. Yellow activates the cooling system, engaging the air conditioner. Green manages the fan operation, circulating air throughout the home.
Often, a Blue wire is present for common (C) voltage, though it’s optional for battery-powered setups. Carefully examine existing wiring at the old thermostat, noting the color and terminal connections.
If unsure, consult the system’s documentation or a qualified HVAC technician. Misidentifying wires can cause system damage or incorrect operation. Label each wire before disconnecting it to avoid confusion during the new thermostat’s installation.
Wiring Heat Pump Systems
Heat pump wiring differs from conventional systems due to reversing valve control. The ‘Y’ wire still activates cooling, but the ‘O/B’ wire controls the reversing valve, switching between heating and cooling modes. The factory setting for ‘O/B’ is typically ‘O’ for cooling. If your system requires ‘B’ for heating, configuration within the installer setup is essential.
A common wire (‘C’) is often required for reliable heat pump operation, providing constant power to the thermostat. Ensure proper identification of the ‘G’ wire for fan control. Incorrect ‘O/B’ configuration will result in the system heating when it should cool, or vice versa.
Double-check wiring against your heat pump’s specific schematic before powering on the system.
Identifying Heat Pump System Wires
Heat pump systems utilize specific wire designations crucial for correct thermostat operation. The ‘Y’ wire consistently represents cooling activation, while ‘G’ controls the indoor fan. However, the ‘O/B’ wire is unique, functioning as the reversing valve control – determining heating or cooling. Identifying whether your system uses ‘O’ (cooling) or ‘B’ (heating) for this wire is paramount.
A ‘W’ wire may be present for auxiliary or emergency heat; The ‘R’ wire provides the primary 24VAC power. A ‘C’ wire, the common wire, is often necessary for consistent power, especially with heat pumps. Carefully compare existing wiring to your system’s documentation.
Misidentifying these wires can lead to improper system function.
Configuring the Changeover Valve (O/B Terminal)
Proper configuration of the O/B terminal is vital for correct heat pump operation. During installer setup, you must define whether your heat pump utilizes the ‘O’ wire for cooling or the ‘B’ wire for heating. The factory setting is typically ‘O’ for cooling. If your system activates heating with the ‘O’ wire, you’ll need to change this setting within the thermostat’s configuration menu.
Incorrect configuration will result in reversed heating and cooling. Access the installer setup mode, navigate to the system type options, and select the appropriate ‘O’ or ‘B’ setting. Double-check your system’s wiring diagram to confirm the correct setting before finalizing.
This ensures the reversing valve operates as intended.
Thermostat Mounting
Securely attach the thermostat to the installed wallplate, ensuring a snug fit. Gently align and press until it clicks, verifying a stable connection.
Attaching the Thermostat to the Wallplate
Carefully align the thermostat body with the mounted wallplate. Ensure the wiring connections are neatly tucked inside the wallplate opening to prevent damage or shorts. Gently press the thermostat onto the wallplate; you should hear a distinct click as it securely locks into place.
Verify the thermostat is firmly attached and doesn’t wobble. A loose connection can cause intermittent operation or inaccurate temperature readings. If it doesn’t snap on easily, double-check the alignment and wiring. Do not force it! Once attached, lightly tug on the thermostat to confirm it’s securely fastened to the wallplate. This simple step ensures reliable performance and prevents future issues.
Installer Setup & Configuration
Access installer settings to customize the thermostat for your specific heating and cooling system, including system type and jumper settings for optimal performance.
System Type Selection (Heat Only)
For systems utilizing only heating, the thermostat must be correctly configured within the installer setup menu. This ensures proper operation and prevents unintended cooling activation. To select “Heat Only” mode, navigate through the installer settings using the thermostat’s interface. This typically involves accessing a setup menu, often hidden behind a button combination or by removing the thermostat from its wallplate.
Once in the setup menu, locate the “System Type” option and select “Heat Only”. Confirm your selection and exit the setup menu. Proper system type selection is crucial for accurate temperature control and efficient energy usage. Incorrect settings can lead to the thermostat attempting to control cooling functions when only heating is available, resulting in system malfunction or discomfort.
Removing the Factory-Installed Jumper
The Honeywell TH5220D1029 thermostat includes a factory-installed jumper that must be removed in specific two-transformer system configurations. This jumper provides a connection for single-transformer setups, but interferes with proper operation when two separate transformers are utilized for heating and cooling. Locate the jumper on the thermostat’s control board – it’s a small metal connector.
Carefully remove this jumper using pliers or a similar tool. Only remove the jumper if your system employs two transformers. Leaving it in place with a two-transformer system can cause operational issues. Failure to remove the jumper in a two-transformer setup can lead to incorrect voltage readings and potentially damage the thermostat or HVAC system.
Two-Transformer Systems
When installing the Honeywell TH5220D1029 in a two-transformer system, specific steps are crucial for correct operation. These systems utilize separate transformers for heating and cooling, requiring the removal of the factory-installed jumper. This jumper, present in single-transformer setups, must be disconnected to prevent voltage conflicts and ensure proper functionality.
Confirm your system utilizes two transformers before proceeding with jumper removal. Incorrectly removing the jumper in a single-transformer system will disrupt operation. After removing the jumper, verify all wiring connections are secure and correspond to the system’s wiring diagram. Proper configuration is essential for reliable heating and cooling performance in two-transformer applications.
Optional 24VAC Common Connection (C Terminal)
The C (Common) wire terminal offers an optional connection for consistent power to the Honeywell TH5220D1029 thermostat. While battery power is sufficient for operation, a 24VAC common wire provides a reliable, continuous power source, enhancing thermostat responsiveness and features. It’s particularly beneficial for systems experiencing intermittent battery performance or utilizing advanced functionalities.
If a C wire is available, connect it to the designated ‘C’ terminal on the thermostat’s wallplate. In the Installer Setup menu, ensure the system is configured to recognize and utilize the C wire connection. If a C wire isn’t present, the thermostat will function normally on battery power alone.
Special Functions
The TH5220D offers features like configurable changeover valves (O/B terminal) for heat pumps and optional C-wire functionality for reliable power.
Understanding the C (Common) Wire
The C (Common) wire provides a dedicated 24VAC reference point, ensuring consistent power to the thermostat, especially crucial for systems with advanced features or when using millivolt systems. While optional when relying solely on battery power, connecting a C-wire significantly enhances thermostat reliability and eliminates potential issues like flickering displays or unexpected resets.
For systems lacking a C-wire, consider utilizing a C-wire adapter kit. These kits repurpose existing wires to establish a common connection. However, ensure compatibility with your HVAC system before installation. If your system is a two-transformer system, remove the factory-installed jumper to enable the C terminal functionality. Proper C-wire connection guarantees stable operation and unlocks the full potential of your Honeywell TH5220D1029 thermostat.
Specifications
The TH5220D1029 is a non-programmable digital thermostat designed for conventional and heat pump systems, offering reliable temperature control and simple operation.
Technical Specifications of TH5220D1029
Display Type: LCD with backlight for easy readability in various lighting conditions. Temperature Range: 40°F to 90°F (4°C to 32°C) heating and cooling. Power Source: 24VAC common (C) wire or two AA alkaline batteries (included) for backup or primary power. Wiring Terminals: R, W, Y, G, C, O/B. System Compatibility: Compatible with conventional heating and cooling systems, as well as heat pump systems. Dimensions: Approximately 4.7″ x 3.1″ x 1.2″. Accuracy: ±1°F. Operating Humidity: 5% to 95% non-condensing. Agency Listings: UL and CSA listed. Setpoint Temperature Range: Adjustable within the display settings. This thermostat is designed for residential applications and provides basic, reliable temperature control.
Customer Assistance
For support regarding your Honeywell TH5220D1029, please contact Honeywell directly for troubleshooting, warranty information, or further installation guidance.
Honeywell Support Contact Information
For immediate assistance with your Honeywell TH5220D1029 thermostat installation or operation, Honeywell provides several convenient support channels. You can reach their dedicated support team via phone at 1-800-468-1513, available during standard business hours.
Alternatively, extensive self-help resources, including frequently asked questions, detailed troubleshooting guides, and downloadable manuals, are readily accessible on the official Honeywell Home website at honeywellhome.com.
Their website also features a robust online chat function for real-time support from a qualified technician. For specific warranty claims or to locate a local Honeywell authorized dealer, please visit their website or contact customer care directly.
